Server Board S5000PAL/S5000XAL TPS Jumper Block Settings

Revision 2.0

Intel order number: D31979-011

6.3 External RJ45 Serial Port Jumper Block

The jumper block J8A3, located directly behind the external RJ45 serial port, is used to

configure either a DSR or a DCD signal to the connector.

TP02303

J8A3

1-2: DCD to DTR 3-4: DSR to DTR

(factory default)

Figure 20. External RJ45 Serial Port Configuration Jumper
